Shearwater TERIC - Blue

Full Colour. High Resolution. AMOLED.

Intuitive controls and menu navigation along with a bright, vivid colour display. With a high degree of customization, the Teric brings divers a timepiece and dive computer of unprecedented capabilities.

The Teric from Shearwater Research of Canada is a full technical dive computer with recreational divers in mind. The Teric includes open-circuit and closed-circuit Air, Nitrox and Trimix multi-gas functionality along with a three-axis tilt-compensated digital compass. It has Recreational, Gauge, Freediving, Open-Circuit Tech and Closed-Circuit/Bail-Out modes. The Teric has four buttons and incorporates situation adaptable logic menus to make operating and diving the Teric very intuitive. The Teric is also very configurable; for example you can set a button to give you a single press access to different tools like compass, stopwatch, countdown timer, etc. There are haptic (vibration) and audible alarms that can be disabled (none, either, both) to prevent annoying other divers in the vicinity.

The Teric offers an information screen utilizing a { 1.39 in | 35 mm } full color AMOLED display with a { 2.16 in x 0.71 in | 55 mm x 18 mm } body and { 4.25 oz | 120.4 g } weight. Brightness levels are user adjustable and accessible with just one button press. During a decompression dive, the Teric provides complete information displays of all required stop times. The Teric can provide time-to-surface based on "look ahead" at planned gas switches. Multiple gas definition presets are supported with any combination of oxygen, nitrogen and helium. The Teric will NOT "lockout" after a missed stop or ascent rate violation. After the dive, the Teric communicates via Bluetooth to connect with the Shearwater Cloud dive log manager, which is compatible with MS Windows, OS X, iOS and Android devices, supporting wireless log downloads and firmware updates. The software can be downloaded from Shearwater's website along with the manual

The Teric supports hoseless gas pressure integration, sometimes called air integration (AI). The Teric is capable of wirelessly connecting to optional transmitters giving the diver ability to monitor up to four tank pressures. It is also capable of calculating the Gas Time Remaining (GTR). Air integration is optional for all modes, from OC Rec to CC/BO. The tank pressure(s), in PSI or BAR, and GTR can be displayed to the customizable slots on the main display screen or accessed through the underlying information screens. The transmitter may be installed directly into the first stage or installed on a short HP hose if desired. Reminder that if you are planning to use the transmitter on a short HP hose then an AIR SPOOL IS REQUIRED.

The Teric has been designed with a wireless rechargeable battery and includes a wireless induction charger stand. Typical dive time on a single charge is at least 30 hours and as much as 50 hours, depending on the features enabled. Although Shearwater recommends using their charging stand, the Teric can also be charged by the flat mats that support the Qi wireless-charging standard (which includes the latest iPhones and many Android phones).

Feature Highlights

• Air/Nitrox/Trimix capable
• 5 open-circuit gas switch presets
• Bühlmann ZHL-16C algorithm with configurable Gradient Factors (no VPM)
• GF presets for sport diving NDL safety factor: High = 35/75, Medium = 40/85, Low = 45/95, plus user defined GF
• Multi-compartment tissue saturation bar graphs
• %CNS oxygen exposure tracking
• Ascent rate monitor
• Haptic (vibration) and audible alarms that can be disabled (none, either, both)
• Date, time and temp display
• Easy to read AMOLED color screen with user configurable "Big Layout" display
• Easy to use adaptive menus with support for multiple languages
• Extensive "home screen" customization options
• User configurable units: imperial (feet, psi) or metric (meters, bar)
• Logbook of last 500 hours of diving
• Operational to at least { 660 ft | 200 m }
• Battery charge level and warning
• Battery life typically 30+ hours of diving with AI mode enabled

Rebreather Features

• Constant PPO2 Set Point
• Automatic Set Point Switching
• 5 additional CCR Diluent gas presets
• 2 button push OC bailout
• Does NOT support external PO2 monitoring

Also...

• Richly featured gauge-mode and freediving mode
• Daily wear timepiece mode with a selection of watch faces
• Three-axis tilt-compensated digital compass
• Engineered polymer body utilizing an exceptionally scratch resistant sapphire crystal face
• Stainless steel bezel with durable PVD coating
• Wrist strap material is shore 70A silicone that has a good balance between strength and elasticity
• Bluetooth Smart wireless upload/download
• Wireless Tank Pressure (option transmitter required)
• User upgradeable firmware
• Wireless rechargeable battery (factory replaceable)
• Shearwater Cloud Dive Log Software
• Two Year Limited Warranty

Recreational Open-Circuit Features

Key features of the Recreational Open-Circuit mode (aka Recreational Nitrox mode) include a simpler menu structure, less cluttered display with a larger font and configurable bottom row, optional safety stops, and a no-decompression limit dive planner. The simplified settings allow for three breathing gas mixtures (Air or Nitrox) and places a greater emphasis on the maximum operating depth (MOD) and no decompression time limit (NDL). The display prominently warns the diver if their depth is near, at or exceeds the MOD of the selected breathing gas. Optional safety stops are user configurable to be 3, 4, 5 mins or adaptable. When using the Adapt setting, a 3 minute safety stop will be used, unless the dive exceeds { 100ft | 30m } or the NDL falls below 5 minutes, in which case a 5 minute safety stop is used. If the diver exceeds the NDL and requires stops, the display turns red and warns "DECO STOP" with the mandatory depth and stop times.
